Tuthill Nadrowski back pressure steam turbine C4.S-GIII
from 2004,
only turbine (was used as a pump drive).
1 available
Inlet pressure 90 bar, outlet pressure 18 bar
Price: €19,500,
plus VAT and FCA free
Tuthill Nadrowski C4.S-GIII steam turbine
| Manufacturer: | TUTHILL Nadrowski |
| Model: | C4.S-G III |
| Type: | steam back pressure |
| Serial number: | 21004 |
| Power [kW]: | 537 |
| Pressure input [bar]: | 90 |
| Temperature input [°C] | 378 |
| Pressure output [bar]: | 18 |
| Speed (1/min) | 3.554 |
| Year of manufacture: | 2004 |
| used: | operational |
| Weight [kg]: | 2.440 |
| Dimensions LxWxH [cm]: | 370x138x174 |
Images
Documents
| manual | inspection report |
