Tuthill Coppus Condensing Steam Turbine RLHA24
Power generators from 1999,
with control, heat exchanger and silencer, steam condenser optional.
2 Available
Inlet pressure 16 bar, outlet pressure 0.7 bar,
486 KWel x 1,500 rpm, 400 V/50 Hz.
AC Generator: MarelliMotori M8B 400 SB 4, 700 KVA
Price: €55,000 each,
plus VAT and FCA-free.
Steam condenser: 4,690 KW Tubetech air-cooled steam condenser
Steam turbine Tuthill Coppus RLHA24
| Manufacturer: | TUTHILL Coppus |
| Model: | RLHA 24 |
| Type: | Steam condensation |
| Serial number: | 99H5046 |
| Performance mech. [kW]: | 525 |
| Pressure input [bar]: | 16 |
| Temperature input [°C] | 350 |
| Pressure output [bar]: | 0,70 |
| Year of manufacture: | 1999 |
| Weight [kg]: | 7600 |
| Dimensions LxWxH [m]: | 4.6 x 2.1 x 2.2 |
AC generator MarelliMotori M8B 400 SB 4
| Manufacturer: | MarelliMotori |
| Model: | M8B 400 SB 4 |
| Type: | AC synchronous generator |
| Serial number: | ME-7070 |
| Power [KVA]: | 700 |
| Voltage [V]: | 400 |
| Frequency [Hz]: | 50 |
| Current [A]: | 1010 |
| Speed [1/min]: | 1500 |
| Year of manufacture: | 1999 |
| Weight [kg]: | 1730 |
| Dimensions LxWxH [m]: | – |
Images
Documents
| Technical drawings | Data and steam diagram | Video on YouTube | Complete documentation (several MB) |
