Siemens condensing steam turbine Twin AFA 46K
Power generator from 2008,
without control and steam condenser
1 available
Inlet pressure 25 bar, outlet pressure -0.8 bar,
3,273 KWel x 1,500 rpm, 6,300 V/50 Hz.
AC generator: AVK DIG 140 I/4, 4,125 KVA
Price: €163,000,
plus VAT, FCA free.
Control: Price on request
Steam condenser: price on request
Steam turbine Siemens Twin AFA 46K
| Manufacturer: | Siemens |
| Model: | Twin AFA 46K |
| Type: | Steam condensation |
| Serial number: | 4.746.153 |
| Power [KW]: | 3.390 |
| Pressure input [bar]: | 25 |
| Temperature input [°C] | 400 |
| Pressure output [bar]: | -0,80 |
| Year of manufacture: | 2008 |
| Weight [kg]: | – |
| Dimensions LxWxH [cm]: | – |
AC generator AVK DIG 140 I/4
| Manufacturer: | AVK |
| Model: | DIG 140 I/4 |
| Type: | AC synchronous generator |
| Serial number: | 8328960 A101 |
| Power [KVA]: | 4.125 |
| Voltage [V]: | 6.300 |
| Frequency [Hz]: | 50 |
| Current [A]: | 378 |
| Speed [1/min]: | 1.500 |
| Year of manufacture: | 2008 |
| Weight [kg]: | 11.400 |
| Dimensions LxWxH [cm]: | – |
Images
Documents
| Data and steam diagram | Operation Manual DE | Video YouTube |
