KKK Condensing Steam Turbine Twin AFA46 GT6
Power generator from 2004,
without control and steam condenser.
1 available
Inlet pressure 29 bar, outlet pressure -0.8 bar,
2,500 KWel x 1,500 rpm, 6,300 V/50 Hz.
AC Generator: Leroy Somer LSA 54 L75-4P, 3,194 KVA
Price: 109,000 €,
plus VAT, FCA free.
Steam condenser: price on request
Steam turbine KKK Twin AFA46 GT6
| Manufacturer: | KKK |
| Model: | AFA 46 GT6 |
| Type: | Steam condensation |
| Serial number: | 4.746.137 |
| Power [KW]: | 2.613 |
| Pressure input [bar]: | 29 |
| Temperature input [°C] | 360 |
| Pressure output [bar]: | -0.8 |
| Year of manufacture: | 2004 |
| Weight [kg]: | – |
| Dimensions LxWxH [cm]: | – |
AC generator Leroy Somer LSA 54 L75-4P
| Manufacturer: | Leroy Somer |
| Model: | LSA 54 L75-4P |
| Type: | AC synchronous generator |
| Serial number: | 600054-1 |
| Power [KVA]: | 3.194 |
| Voltage [V]: | 6.300 |
| Frequency [Hz]: | 50 |
| Current [A]: | 293 |
| Speed [1/min]: | 1.500 |
| Year of manufacture: | 2004 |
| Weight [kg]: | 8.070 |
| Dimensions LxWxH [cm]: | 340×140 |
Images
Documents
| Endoscopy report | Steam diagram | Technical description | Video YouTube |
