AEG-Kanis Back Pressure Steam Turbine G20
Power generator from 1985,
Turbine and generator.
1 available
Inlet pressure 13 bar, outlet pressure 5 bar,
2,046 KWel x 1,500 rpm, 5,250 V/50 Hz.
AC generator: AEG DKBH 4565/04, 2,850 KVA
Price: €85,000,
plus VAT, FCA free.
Steam turbine AEG-Kanis G20
| Manufacturer: | AEG-Kanis |
| Model: | G 20 |
| Type: | steam back pressure |
| Serial number: | 18910/000 |
| Power [kW]: | 2046 |
| Pressure input [bar]: | 13 |
| Temperature input [°C] | 320 |
| Pressure output [bar]: | 5 |
| Year of manufacture: | 1985 |
| Weight [kg]: | – |
| Dimensions LxWxH [cm]: | – |
AC generator AEG DKBH 4565/04
| Manufacturer: | AEG |
| Model: | DKBH 4565/04 |
| Type: | AC synchronous generator |
| Serial number: | 85 476 902 |
| Power [KVA]: | 2.850 |
| Voltage [V]: | 5.250 |
| Frequency [Hz]: | 50 |
| Current [A]: | 231 |
| Speed [1/min]: | 1.500 |
| Year of manufacture: | 1983 |
| Weight [kg]: | – |
| Dimensions LxWxH [cm]: | – |
Images
Documents
| Technical drawings | Steam diagrams | Video on YouTube |
