KKK back pressure steam turbine CFR5 G6B
Generator from 2006 with 102,000 operating hours,
Turbine with control and AC generator.
1 available
Inlet pressure 64 bar, outlet pressure 8.5 bar,
3,817 KWel x 1,500 rpm, 6,300 V/50 Hz.
AC generator: INDAR BZK-710-S-4, 5,000 KVA
Price: €193,000,
plus VAT, FCA free.
Steam turbine KKK CFR5 G6B
| Manufacturer: | KKK |
| Model: | CFR5 G6B |
| Type: | steam back pressure |
| Serial number: | 4 556 007 |
| Power [kW]: | 3.817 |
| Pressure input [bar]: | 64 |
| Temperature input [°C] | 460 |
| Pressure output [bar]: | 8,5 |
| Year of manufacture: | 2006 |
| Operating hours [h]: | 102.000 |
| Weight [kg]: | 12.500 |
| Dimensions LxWxH [cm]: | 3.3 x 2.2 x 2.1 |
AC Generator INDAR BZK-710-S-4
| Manufacturer: | INDAR |
| Model: | BZK-710-S-4 |
| Type: | AC synchronous generator |
| Serial number: | 16537 |
| Power [KVA]: | 5.000 |
| Voltage [V]: | 6.300 |
| Frequency [Hz]: | 50 |
| Current [A]: | 459 |
| Speed [1/min]: | 1.500 |
| Year of manufacture: | 2006 |
| Weight [kg]: | 8.140 |
| Dimensions LxWxH [cm]: | – |
Images
Documents
| Tech. Data | Steam diagram | Video on YouTube |
